John Deere 50

Series: John Deere Mini Excavator

Source: https://www.deere.ch/de/traktoren/klein-traktoren/traktoren-
The 50 from John Deere is part of the John Deere Mini Excavator series. The engine delivers 29.1 kW, has 4 cylinders, with a displacement of 1,638.7 cm³. Torque is 124.7 Nm. Rated speed is 2,650 rpm. The unladen weight is 4,204.8 kg. Ground clearance is 332.2 mm. The tank holds 54.1 litres. Maximum torque is reached at 1,800 rpm. The pump delivers 126.4 l/min. The hydraulic tank holds 104.9 litres. Working pressure is 166.9 bar. The cooling system holds 7.6 litres. The oil fill is 7.6 litres. The electrical system runs on 12 V. The engine fitted is the 4TN78T-RJB. The John Deere Mini Excavator series covers 12 models. Rated output within it ranges from 9.2 to 29.1 kW; the 50 sits at the top of that range with 29.1 kW. Its immediate neighbours are the 35C ZTS below it with 23.9 kW. 2153 John Deere models across 96 series are on record. The model is listed under Excavators & compaction. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine model4TN78T-RJBcorrect
Power29.1 kWcorrect
Rated speed2,650 rpmcorrect
Torque124.7correct
Speed at max. torque1,800 rpmcorrect
Cylinders4correct
Displacement1,638.7 cm³correct
Coolant capacity7.6 lcorrect
Engine oil capacity7.6 lcorrect

Dimensions and weights

Ground clearance332.2correct
Unladen weight4,204.8 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow126.4 l/mincorrect
Hydraulic oil capacity104.9 lcorrect
Hydraulic pressure166.9 barcorrect
Fuel tank capacity54.1 lcorrect

Other data

Height2,450.6correct

Where this model stands

Power-to-weight ratio: 6.9 kW/t (29 kW / 4.2 t)

Stronger than 85% of the mini excavators in the register — out of 400 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 50 have?

The John Deere 50 delivers 29.1 kW.

How much does the John Deere 50 weigh?

The unladen weight is 4,205 kg.

What engine does the John Deere 50 have?

4 cylinders, 1,639 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
