JCB VM132PD

Series: JCB Vibratory Compactor

Source: https://www.jcb.com/en-GB/parts-and-service/service/reman/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The JCB VM132PD is a model in the JCB Vibratory Compactor series. The engine delivers 152.1 hp (111.9 kW), has 6 cylinders, with a displacement of 5,883 cm³. Rated speed is 2,200 rpm. The unladen weight is 13,400 kg. Ground clearance is 447 mm. Top speed is 12.7 km/h. The tank holds 400.1 litres. The hydraulic tank holds 80.3 litres. The cooling system holds 19.3 litres. The oil fill is 14.4 litres. The electrical system runs on 12 V. The engine fitted is the B5,9 - 150C. The JCB Vibratory Compactor series covers 8 models. Rated output within it ranges from 23.1 to 175.4 hp; the VM132PD sits in the upper part of that range with 152.1 hp. Its immediate neighbours are the VM115PD below it with 126.7 hp and the VM146PD above it with 175.4 hp. 752 JCB models across 38 series are on record. The model is listed under Road construction. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelB5.9 - 150Ccorrect
Power152.1 hp (111.9 kW)correct
Rated speed2,200 rpmcorrect
Cylinders6correct
Displacement5,883 cm³correct
Aspirationturbochargedcorrect
Coolant capacity19.3 lcorrect
Engine oil capacity14.4 lcorrect

Dimensions and weights

Ground clearance447correct
Unladen weight13,400 kgcorrect

Drivetrain and chassis

Top speed12.7 km/hcorrect
System voltage12 Vcorrect

Working data

Hydraulic oil capacity80.3 lcorrect
Fuel tank capacity400.1 lcorrect

Other data

Height2,935.2correct

Where this model stands

Power-to-weight ratio: 8.4 kW/t (112 kW / 13.4 t)

Stronger than 50% of the compaction equipment in the register — out of 223 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the JCB VM132PD have?

The JCB VM132PD delivers 152 hp.

How much does the JCB VM132PD weigh?

The unladen weight is 13,400 kg.

What engine does the JCB VM132PD have?

6 cylinders, 5,883 cm³ displacement.

How fast does the JCB VM132PD go?

Top speed is 12.7 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 16 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
