JCB VM115D

Series: JCB Vibratory Smooth Drum Roller

Source: http://machinestore.jcb.com/de/machines/mini-excavators/8008

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the VM115D, JCB offers a model from the JCB Vibratory Smooth Drum Roller series. The engine delivers 126.7 hp (93.2 kW), has 4 cylinders, with a displacement of 4,391.7 cm³. Rated speed is 2,200 rpm. The unladen weight is 11,299.9 kg. Ground clearance is 447 mm. Top speed is 10.6 km/h. The tank holds 300.2 litres. The hydraulic tank holds 80.3 litres. The cooling system holds 14 litres. The oil fill is 11 litres. The electrical system runs on 12 V. The engine fitted is the JBC444TA. The JCB Vibratory Smooth Drum Roller series covers 22 models. Rated output within it ranges from 29.6 to 175.4 hp; the VM115D sits in the upper part of that range with 126.7 hp. Its immediate neighbours are the VM75D below it with 81.1 hp and the VM132D above it with 152.1 hp. 752 JCB models across 38 series are on record. The model is listed under Road construction. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelJBC444TAcorrect
Power126.7 hp (93.2 kW)correct
Rated speed2,200 rpmcorrect
Cylinders4correct
Displacement4,391.7 cm³correct
Aspirationturbochargedcorrect
Coolant capacity14 lcorrect
Engine oil capacity11 lcorrect

Dimensions and weights

Width2,252.5correct
Ground clearance447correct
Unladen weight11,299.9 kgcorrect

Drivetrain and chassis

Top speed10.6 km/hcorrect
System voltage12 Vcorrect

Working data

Hydraulic oil capacity80.3 lcorrect
Fuel tank capacity300.2 lcorrect

Other data

Height2,935.2correct

Where this model stands

Power-to-weight ratio: 8.2 kW/t (93 kW / 11.3 t)

Stronger than 64% of the road construction in the register — out of 669 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the JCB VM115D have?

The JCB VM115D delivers 127 hp.

How much does the JCB VM115D weigh?

The unladen weight is 11,300 kg.

What engine does the JCB VM115D have?

4 cylinders, 4,392 cm³ displacement.

How fast does the JCB VM115D go?

Top speed is 10.6 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
