JCB 300
Series: JCB Skid Steer Loader
The JCB 300 is a model in the JCB Skid Steer Loader series. The engine delivers 75 hp (55.2 kW), with a displacement of 4,391.7 cm³. Torque is 400.1 Nm. Rated speed is 2,400 rpm. The wheelbase measures 1,252.7 mm. Ground clearance is 250.2 mm. Top speed is 20 km/h. The tank holds 103.3 litres. Maximum torque is reached at 1,200 rpm. The pump delivers 90.1 l/min. The hydraulic tank holds 55.3 litres. Working pressure is 229.9 bar. The cooling system holds 15.5 litres. The electrical system runs on 12 V. The engine fitted is the EcoMAX TCAE-55. Tyre size: 12 x 16,5. The JCB Skid Steer Loader series covers 16 models. Rated output within it ranges from 47.7 to 93.3 hp; the 300 sits in the middle of that range with 75 hp. Its immediate neighbours are the 270 below it with 74.8 hp and the 190 above it with 81.1 hp. 752 JCB models across 38 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | EcoMAX TCAE-55correct |
|---|---|
| Power | 75 hp (55.2 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Torque | 400.1correct |
| Speed at max. torque | 1,200 rpmcorrect |
| Displacement | 4,391.7 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 15.5 lcorrect |
Dimensions and weights
| Wheelbase | 1,252.7correct |
|---|---|
| Ground clearance | 250.2correct |
Drivetrain and chassis
| Tyre size | 12 x 16.5correct |
|---|---|
| Top speed | 20 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 90.1 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 55.3 lcorrect |
| Hydraulic pressure | 229.9correct |
| Fuel tank capacity | 103.3 lcorrect |
Other data
| Height | 2,090.9correct |
|---|
Frequently asked questions
How much power does the JCB 300 have?
The JCB 300 delivers 75 hp.
What engine does the JCB 300 have?
4,392 cm³ displacement.
How fast does the JCB 300 go?
Top speed is 20 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
