Iveco ML 120E25D
Built: 2009-2009 · Series: ML
More machines from model year 2009
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Iveco ML – the collective page of medium-duty truck chassis outside the named ranges, from the ML 75 to the ML 180, four- and six-cylinders of 3.9 to 5.9 litres, 100 to 205 kW
This page gathers the versions of the Iveco ML range, medium-duty chassis in the region of about 7.5 to just under 18 tonnes gross vehicle weight. The type designation follows the pattern usual for Iveco in this vehicle class: the first digits give the weight class (ML 75 about 7.5 t, ML 120 about 12 t, ML 180 about 18 t), the letter E stands for the engine generation, the following number for the engine output in hp (E18 about 180 hp, E25 about 250 hp, E28 about 280 hp); the suffix K usually marks all-wheel-drive chassis in Iveco nomenclature, P chassis with a particularly long wheelbase for bodywork. The chassis form the base for box bodies, tippers, crane vehicles and fire engines.
Read on 3 more paragraphs
The register lists here 55 versions with 100 to 205 kW from four- and six-cylinders of 3,900 to 5,880 cm³, unladen weights from 3,600 to 17,620 kg, gross weights from 6,990 to 24,600 kg, lengths from 5,200 to 11,450 mm and widths from 2,190 to 2,600 mm.
The medium-duty class between 7.5 and 18 tonnes is the backbone of urban distribution transport and municipal fleets; Iveco competes there with chassis of this size class against MAN, Mercedes-Benz Atego and Volvo FL.
On used examples, operating hours and the engine's service history, condition of clutch and manual gearbox, rust on the frame and body subframe count, and on all-wheel-drive chassis the transfer case and axles as well as brakes and suspension; parts run through the Iveco dealer network.
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 5,880 cm³correct |
Dimensions and weights
| Length | 9,550 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 5,180 mmcorrect |
| Unladen weight | 6,410 kgcorrect |
| Gross vehicle weight | 11,990 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 90 km/hcorrect |
Frequently asked questions
How much does the Iveco ML 120E25D weigh?
The unladen weight is 6,410 kg.
What is the gross vehicle weight of the Iveco ML 120E25D?
11,990 kg.
What engine does the Iveco ML 120E25D have?
6 cylinders, 5,880 cm³ displacement.
How fast does the Iveco ML 120E25D go?
Top speed is 90 km/h.
What are the dimensions of the Iveco ML 120E25D?
9,550 mm × 2,550 mm.
When was the Iveco ML 120E25D built?
Production years: 2009.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
