Iveco EMOSS 812

Built: 2009-2009 · Series: Trucks 3.5–12 t (Class N2)

More machines from model year 2009

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the EMOSS 812, Iveco offers a model from the Lkw 3,5–12 t (Klasse N2) series. Production: 2009. The machine is 5,900 mm long and 2,300 mm wide. The unladen weight is 6,887 kg. The wheelbase measures 3,690 mm. The gross vehicle weight is 10,000 kg. The machine runs on 4 wheels. The Lkw 3,5–12 t (Klasse N2) series covers 689 models. Unladen weight within it ranges from 2,100 to 10,955 kg; the EMOSS 812 sits in the middle of that range with 6,887 kg. Its immediate neighbours are the ML120E18/P EEV below it with 6,860 kg and the ML120EL22D/P above it with 6,895 kg. Gross vehicle weight within it ranges from 3,510 to 12,000 kg; here the EMOSS 812 sits in the upper part of that range with 10,000 kg. 3135 Iveco models across 106 series are on record.

Iveco Eurocargo — what the type code numbers actually mean

The Iveco Eurocargo type designation, for example '75E16', follows a fixed three-part pattern. The first two or three digits give the gross vehicle weight in steps of 0.1 tonnes, so '75' stands for 7.5 t and '120' for 12.0 t. The letter 'E' marks the engine family — on current models the Tector diesel. The final two digits, multiplied by ten, give the approximate power rating in metric horsepower: '16' means around 160 hp, '18' around 180 hp, and '28' around 280 hp.

Read on 4 more paragraphs

This pattern is confirmed by documented examples: a Eurocargo 75E16 has a gross vehicle weight of 7,500 kg and a 3.9-litre Tector engine rated at 118 kW (around 160 hp), while a 120E18 carries a 12.0-tonne gross weight and 180 hp. The Tector engine itself comes as a four-cylinder 4.5-litre unit in 160, 190 and 210 hp stages, and as a six-cylinder 6.7-litre unit from 220 to 320 hp. The two-digit suffix alone therefore does not reveal whether a truck has four or six cylinders — that depends on the gross weight bracket and model year.

The upper end of the Iveco Daily range — the 50C, 65C and 70C variants — technically also falls into class N2, even though it belongs to the Daily rather than the Eurocargo model family. Iveco offers the Daily up to a gross vehicle weight of 7.2 t, which puts it above the 3.5-tonne threshold separating light vans from medium-duty trucks. For buyers and workshops this means a 70C sits closer, by weight, to the smallest Eurocargo than to a Daily panel van under 3.5 t, despite sharing the Daily name.

Within the Eurocargo range itself, the type codes span more than class N2: variants such as the 180E28, with an 18.0-tonne gross vehicle weight, already belong to the heavy N3 class. That means vehicles sold under the single 'Eurocargo' name span more than one type-approval class, so the first number in the type code is a more reliable reference point than the model name alone.

When buying used, it is worth checking the type designation against the gross vehicle weight stated on the registration document — the two should match, since a previous owner downrating the tonnage does not automatically change the code on the vehicle. The power suffix alone also says nothing about actual payload, which depends further on the body's kerb weight. Anyone looking specifically for a four- or six-cylinder engine should not rely on the type code but check the engine code and displacement on the registration document or on the engine itself.

Sources: Eurotransport: Test Eurocargo 75E16 (7.500 kg zulässiges Gesamtgewicht, Tector 3,9 l, 118 kW/160 PS), L'Argus: Fiche technique Eurocargo 120E18 Tector, TruckScout24: Eurocargo 180E28 Angebot, Iveco: Eurocargo-Broschüre (Tector-Motorenprogramm, Vier- und Sechszylinder), Iveco: Daily 7-Tonner (zulässiges Gesamtgewicht bis 7,2 t)

Technical data

Dimensions and weights

Length5,900 mmcorrect
Width2,300 mmcorrect
Wheelbase3,690 mmcorrect
Unladen weight6,887 kgcorrect
Gross vehicle weight10,000 kgcorrect

Drivetrain and chassis

Wheels4correct

Frequently asked questions

How much does the Iveco EMOSS 812 weigh?

The unladen weight is 6,887 kg.

What is the gross vehicle weight of the Iveco EMOSS 812?

10,000 kg.

What are the dimensions of the Iveco EMOSS 812?

5,900 mm × 2,300 mm.

When was the Iveco EMOSS 812 built?

Production years: 2009.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
