Ingersoll Rand DD138HF
Series: Ingersoll Rand Vibratory Smooth Drum Roller
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Ingersoll Rand DD rollers: what the number after the letters means
At Ingersoll Rand, "DD" stands for double drum: this line covers vibratory rollers with two smooth drums for asphalt and soil compaction, from small tandem rollers to heavy construction-grade machines. The number after the letters — 16, 22, 24, 29, 30, 70, 90 in this bucket — marks the size/weight class: the higher the number, the heavier the machine.
Read on 4 more paragraphs
Extra letters such as the "S" in DD10S mark variants within a size class; when in doubt, the nameplate or that specific model's manual is the reliable source, since SpecCodex does not carry a confirmed meaning for the addition.
The bucket's 40 live-listed models show the spread: engine output 12 to 152 kW, operating weight 1,317 to 20,411 kg — everything from a handy trench roller to a heavy tandem roller for road building.
For a used vibratory roller, drum condition matters most: out-of-round drums, dents, and cracks on the running surface permanently reduce compaction quality. Add a function test of the vibration system (exciter, bearings), a check of the drum water-spray system on asphalt rollers, and a comparison of recorded hours against visible wear.
In short: DD means double drum, the following number is the weight class. When choosing between close numbers like DD24 and DD29, compare operating weight and drum width directly rather than relying on the model number alone.
Sources: Kennwerte der Modelle Ingersoll Rand Vibratory Smooth Drum Roller, — MachineryTrader: Ingersoll Rand DD24 Listings, — Purple Wave: Ingersoll Rand Double Drum Roller Compactor, Wikipedia: Road roller (Wikipedia)
Technical data
Engine
| Engine model | B5.9-173correct |
|---|---|
| Power | 129 kWcorrect |
Dimensions and weights
| Length | 6,000 mmcorrect |
|---|---|
| Width | 2,337.8correct |
| Ground clearance | 510correct |
| Unladen weight | 13,030 kgcorrect |
Drivetrain and chassis
| Top speed | 10.6 km/hcorrect |
|---|
Working data
| Hydraulic oil capacity | 138.2 lcorrect |
|---|---|
| Fuel tank capacity | 259.3 lcorrect |
Other data
| Cab height | 3,182.1correct |
|---|---|
| System voltage | 12 Vcorrect |
More machines with this engine (B5.9-173, 2)
Where this model stands
Power-to-weight ratio: 9.9 kW/t (129 kW / 13 t)
Stronger than 89% of the road construction in the register — out of 667 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Ingersoll Rand DD138HF have?
The Ingersoll Rand DD138HF delivers 129 kW.
How much does the Ingersoll Rand DD138HF weigh?
The unladen weight is 13,030 kg.
How fast does the Ingersoll Rand DD138HF go?
Top speed is 10.6 km/h.
What are the dimensions of the Ingersoll Rand DD138HF?
6,000 mm × 2,338 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
