Ihi Agri Tech ER49DI/1800C

Built: 2016-2019 · Series: Other models

Source: https://www.technikboerse.com/en/gebraucht/digger-789/ihi-89

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The ER49DI/1800C comes from Ihi Agri Tech. Production: 2016-2019. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 36 kW. The engine is turbocharged. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through direct injection. The charge air is air-cooled. Charging is by a wastegate turbocharger. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Ihi Agri Tech range ranges from 4 to 50 kW; the ER49DI/1800C sits in the upper part of that range with 36 kW. Its immediate neighbours are the GN47/2600 below it with 35 kW and the 50D/2800 above it with 37 kW. 296 Ihi Agri Tech models are on record. The model is listed under Non-road diesel engines. 27 verified figures from 1 source are on file.

Technical data

Engine

Engine codeC2.2correct
Engine familyGH3XL2.22TDIcorrect
Engine familiesHH3XL2.22TDI; GH3XL2.22TDI; KH3XL2.22TDIcorrect
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output36 kWcorrect
Power band37<=kW<56correct
Rated speed1,800 rpmcorrect
Maximum torque193 N·mcorrect
Speed at max. torque1,800 rpmcorrect
Cylinders4correct
Cylinder layoutin linecorrect
Bore84 mmcorrect
Stroke100 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectiondirect injectioncorrect
Aspirationturbochargedcorrect
Turbocharger typewastegate turbochargercorrect
Charge-air coolingaircorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

VersionC2.2correct
Built from2016correct
Built to2019correct
Model year from2016correct
Model year to2019correct
Sales regionbothcorrect

Frequently asked questions

How much power does the Ihi Agri Tech ER49DI/1800C have?

The Ihi Agri Tech ER49DI/1800C delivers 36 kW.

When was the Ihi Agri Tech ER49DI/1800C built?

Production years: 2016-2019.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
