Ihi Agri Tech 452600

Built: 2013-2017 · Series: Other models

Source: https://www.technikboerse.com/en/haendler/claas-main-donau-g

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Ihi Agri Tech 452600 is a machine built by Ihi Agri Tech. Production: 2013-2017. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 45 kW. The engine is turbocharged. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through direct injection. The charge air is air-cooled. Charging is by a wastegate turbocharger. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Ihi Agri Tech range ranges from 4 to 50 kW; the 452600 sits at the top of that range with 45 kW. Its immediate neighbours are the 6372/2600 below it with 43 kW and the GR66B/2800 above it with 49 kW. 296 Ihi Agri Tech models are on record. The model is listed under Non-road diesel engines. 27 verified figures from 1 source are on file.

Technical data

Engine

Engine codeN4LDI-TAcorrect
Engine familyGH3XL2.22TDIcorrect
Engine familiesGH3XL2.22TDI; DH3XL2.22TDI; FH3XL2.22TDI; HH3XL2.22TDI; EH3XL2.22TDIcorrect
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output45 kWcorrect
Power band37<=kW<56correct
Rated speed2,600 rpmcorrect
Maximum torque197 N·mcorrect
Speed at max. torque1,800 rpmcorrect
Cylinders4correct
Cylinder layoutin linecorrect
Bore84 mmcorrect
Stroke100 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectiondirect injectioncorrect
Aspirationturbochargedcorrect
Turbocharger typewastegate turbochargercorrect
Charge-air coolingaircorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

VersionN4LDI-TAcorrect
Built from2013correct
Built to2017correct
Model year from2013correct
Model year to2017correct
Sales regionbothcorrect

Frequently asked questions

How much power does the Ihi Agri Tech 452600 have?

The Ihi Agri Tech 452600 delivers 45 kW.

When was the Ihi Agri Tech 452600 built?

Production years: 2013-2017.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 27 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
