Hoyer MS90L-6

Series: Other models

The photo shows the MS100L-6 from the same series. Source: https://www.hoyer.de/news/die-logische-loesung-fuer-die-logi

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The MS90L-6 from Hoyer is a three-phase induction motor. The rated output is 1.1 kW. The motor is six-pole, which at 50 Hz gives a synchronous speed of 1,000 rpm. The housing is frame size 90 L in foot-mounted form. The protection class is IP56. The efficiency is 78.6 per cent at full load, 79.3 per cent at 75 per cent load and 76.7 per cent at half load. The motor weighs 21 kg. The mounting arrangement to IEC 60034-7 is B5. The motor is built in China. The values are recorded in the Australian MEPS registration under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Hoyer range ranges from 0.75 to 160 kW; the MS90L-6 sits at the bottom of that range with 1.1 kW. Its immediate neighbours are the HMA3 90S-6 below it with 0.75 kW and the HMA2 100L-6 above it with 1.5 kW. 97 Hoyer models are on record. The model is listed under Electric motors. 22 verified figures from 1 source are on file.

Technical data

Engine

Rated output	1.1 kWcorrect

Dimensions and weights

Weight	21 kgcorrect

Electrical data

Number of poles	6correct
Protection class	IP56correct
Frame size	90 L (foot)correct
Mounting (IEC 60034-7)	B5correct
Efficiency at full load	78.63 %correct
Efficiency at 75 % load	79.32 %correct
Efficiency at half load	76.73 %correct

Origin and approval

Country of manufacture	Chinacorrect
Standard applied	Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct
Test method	IEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Hoyer MS90L-6 have?

The Hoyer MS90L-6 delivers 1.1 kW.

What to check before buying

Match the data plate against the order: frame size, mounting and rating have to agree.
Check the ingress rating against the installation site — outdoors or in dust the demands differ.
Hold the mounting form and dimensions against the existing seat before ordering.
The pole count sets the speed — when replacing an older unit, compare this first.
For used units, ask about winding condition and bearing play.
Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
