Halla HA170

Series: Halla Wheel Loader

Source: https://www.kleinanzeigen.de/s-anzeige/radlader-ha180-hoftra

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Halla Wheel Loader series from Halla includes the HA170. The engine delivers 94.7 kW, has 6 cylinders, with a displacement of 5,901 cm³. Torque is 503 Nm. Rated speed is 2,200 rpm. The unladen weight is 9,700 kg. The wheelbase measures 2,651.8 mm. Ground clearance is 365.8 mm. The tank holds 225.2 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 170.3 l/min. The hydraulic tank holds 80.3 litres. The cooling system holds 43.2 litres. The electrical system runs on 24 V. The engine fitted is the 6BT5,9C. Tyre size: 17,5x25 12PR. Rated output across the Halla range ranges from 41.8 to 186.1 kW; the HA170 sits in the lower part of that range with 94.7 kW. Its immediate neighbours are the HE50A below it with 41.8 kW and the HE220LC above it with 112 kW. 7 Halla models across 4 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model	6BT5.9Ccorrect
Power	94.7 kWcorrect
Rated speed	2,200 rpmcorrect
Torque	503correct
Speed at max. torque	1,400 rpmcorrect
Cylinders	6correct
Displacement	5,901 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	43.2 lcorrect

Dimensions and weights

Wheelbase	2,651.8correct
Ground clearance	365.8correct
Unladen weight	9,700 kgcorrect

Drivetrain and chassis

Gearbox type	full powershift transmissioncorrect
Forward gears	4correct
Reverse gears	3correct
Tyre size	17.5x25 12PRcorrect
System voltage	24 Vcorrect

Working data

Pump flow	170.3 l/mincorrect
Hydraulic oil capacity	80.3 lcorrect
Fuel tank capacity	225.2 lcorrect

Other data

Height	3,130.3correct

Where this model stands

Power-to-weight ratio: 9.8 kW/t (95 kW / 9.7 t)

Stronger than 48% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Halla HA170 have?

The Halla HA170 delivers 94.7 kW.

How much does the Halla HA170 weigh?

The unladen weight is 9,700 kg.

What engine does the Halla HA170 have?

6 cylinders, 5,901 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
