Gs Meppel PRS
Built: 2003-2003 · Series: Other models
More machines from model year 2003
GS Meppel – other models: the collective page of heavy low-loader trailers outside the named ranges, gross weights from 14,000 to 48,000 kg, lengths from 7,630 to 13,980 mm, widths from 2,350 to 2,750 mm
This page gathers the GS Meppel trailers the register could not assign to a named range. The name carries the place name of the Dutch town of Meppel in the province of Drenthe. The model list is dominated by short letter codes such as AC, AI, AIC, AN, AV, OB, OI and OTI, each followed by a number code, plus the model name Maxloader.
Read on 3 more paragraphs
The register lists here 52 versions with unladen weights from 3,000 to 17,120 kg and gross weights from 14,000 to 48,000 kg. Lengths lie between 7,630 and 13,980 mm, widths between 2,350 and 2,750 mm.
With gross weights up to 48 tonnes and lengths up to almost 14 metres, these trailers belong to the class of multi-axle low-loaders for carrying construction machinery, agricultural machinery or other self-propelled equipment in heavy haulage. Such trailers are usually paired with a heavy-class tractor unit and are built with extendable ramps or extensions. The span from 3,000 to 17,120 kg unladen weight shows that the range covers both lighter two-axle versions and heavier multi-axle models for large machinery.
On a used low-loader of this size, the condition of frame and load bed, corrosion around the wheel arches and loading areas, the condition and wear of the axles including steering axles, the function of the hydraulic ramps, and brakes and air suspension all matter. The high gross weight makes regular checks of the frame and welds especially important.
Sources: Kennwerte der Modelle GS Meppel (weitere Modelle), RDW (Niederlande)
Technical data
Dimensions and weights
| Length | 13,850 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 8,960 mmcorrect |
| Unladen weight | 8,140 kgcorrect |
| Gross vehicle weight | 35,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Gs Meppel PRS weigh?
The unladen weight is 8,140 kg.
What is the gross vehicle weight of the Gs Meppel PRS?
35,000 kg.
Up to what speed is the Gs Meppel PRS approved?
Approved up to 100 km/h.
What are the dimensions of the Gs Meppel PRS?
13,850 mm × 2,550 mm.
When was the Gs Meppel PRS built?
Production years: 2003.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
