Goldoni Star 3060 LE High 4WD
Series: Star
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Goldoni Star 3060 LE High belongs to the Goldoni 4WD Tractor series. 43 kW is what the three-cylinder engine gets out of 2.1 litres. Rated power is reached at 2,600 rpm.
Top speed is 30 km/h. Unladen weight is 2,040 kg.
Within the range, rated power spans from 16 to 70 kW; with 43 kW, the Star 3060 LE High sits in the mid-field. Directly alongside are the Cluster 65 SN with 36 kW below and the Cluster 75 RS with 49.1 kW above.
Goldoni Star – narrow specialty tractors for vineyards and orchards: Narrow, Vineyard, Orchard and the number in the name
Goldoni of Migliarina di Carpi in Emilia-Romagna is one of Italy's specialists in narrow-track tractors, and the Star series is its offer for vineyards, orchards and greenhouses. These machines are deliberately narrow and low so they can work between tight vine rows and under low canopies without giving up pulling power or hydraulic capacity.
Read on 3 more paragraphs
The number in the name ranks the models roughly by power and size – Star 100 and the 3000 series with the 3050, 3060 and 3070. The suffixes describe the layout: Narrow Orchard and Vineyard stand for especially narrow versions, SL for a low overall height, High and Low separate seating position or ground clearance, Quadrifoglio and Max mark equipment lines, NRG and LE engine or equipment levels.
In the register the models run from 35 to 71 kW with 2,083 to 3,001 cm³ of displacement and three or four cylinders; the rear linkage lifts 2,300 to 2,500 kg depending on model, unladen weight lies between 1,850 and 2,520 kg, and top speed reaches 40 km/h.
Anyone buying a used Star should check the front axle and steering – narrow-track tractors spend much of their life with the wheels turned – as well as the hydraulics and implement mounts, which in orchard work carry sprayers and mulchers under constant load.
Sources: Kennwerte der Modelle Goldoni Star, Goldoni (Hersteller)
Technical data
Engine
| Power | 43 kWcorrect |
|---|---|
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,082.8 cm³correct |
| Aspiration | turbochargedcorrect |
Dimensions and weights
| Length | 3,460 mmcorrect |
|---|---|
| Ground clearance | 290.1correct |
| Unladen weight | 2,040 kgcorrect |
Drivetrain and chassis
| Gearbox type | 40 speeds, a lever can be used to select the 8+8 transmission with synchromesh gearboxcorrect |
|---|---|
| Tyre size | Front 11.0/65x12, Rear 320/85x20correct |
| Top speed | 30.1 km/hcorrect |
| Turning radius | 3,020 mmcorrect |
Working data
| Pump flow | 38.2 l/mincorrect |
|---|---|
| Fuel tank capacity | 50.3 lcorrect |
Other data
| Cab height | 2,130.6correct |
|---|
Where this model stands
Power-to-weight ratio: 21.1 kW/t (43 kW / 2 t)
Power class: Universal (40–100 hp)
Stronger than 41% of the tractors in the register — out of 15,260 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Goldoni Star 3060 LE High have?
The Goldoni Star 3060 LE High delivers 43 kW.
How much does the Goldoni Star 3060 LE High weigh?
The unladen weight is 2,040 kg.
What engine does the Goldoni Star 3060 LE High have?
3 cylinders, 2,083 cm³ displacement.
How fast does the Goldoni Star 3060 LE High go?
Top speed is 30.1 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
