Fantech Y2AE100L24
Series: Y2AE100L2-4
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fantech Y2AE100L2-4 – three-phase motor from the Australian ventilation brand: IEC frame 100, four-pole, 3 kW, IP55, MEPS-registered with three mounting variants
Y2AE100L2-4 is the four-pole version of the Y2AE range from the 100L2 frame band that Fantech, an Australian manufacturer of ventilation and extraction equipment, has registered under Australia's GEMS/MEPS energy efficiency standard. The type designation follows IEC frame-size logic: 100L2 denotes the frame size, and the trailing 4 denotes the pole count – the register confirms four poles across all five versions on this page. Alongside the base model there is a flange version B14 and combined foot-flange variants B3/B5.
Read on 3 more paragraphs
The register lists five versions with a rated output of 3 kW throughout, an efficiency span of 84.9 to 86.2% at full load and 85.5 to 87.4% at 75% load. Frame size stays at 100 across all models, protection is IP55 throughout, and the voltage entries are mostly 400/415/460 V. Manufacturing takes place in China, tested under the 2019 GEMS determination for three-phase motors, mostly using test method 2-1-1B.
As a drive for fans, extract systems and ventilation units, the Y2AE100L2-4 covers a mid output range in Fantech's programme, through which the company supplies mainly the Australia-Pacific market for commercial and residential ventilation. The slightly higher rated output suits duct and axial fans with greater airflow.
When swapping or buying used, check bearing condition, insulation resistance of the winding, visible corrosion on the terminal box and fan cover, and a legible nameplate showing frame size, pole count and protection class. The mounting code needed at the installation point is decisive, since B3, B5 and B14 versions have different fixing geometries. Spare parts run through the Fantech sales network.
Technical data
Engine
| Rated output | 3 kWcorrect |
|---|
Electrical data
| Number of poles | 4correct |
|---|---|
| Protection class | IP55correct |
| Frame size | 100 L (foot)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 86.2 %correct |
| Efficiency at 75 % load | 87.4 %correct |
| Efficiency at half load | 85.5 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 61972correct |
Frequently asked questions
How much power does the Fantech Y2AE100L24 have?
The Fantech Y2AE100L24 delivers 3 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
