Fabbripark D 60
Built: 2012-2012 · Series: Other models
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fabbripark – other models: the collective page of heavy special trailers outside the named ranges, Booster and modular versions, 13 to 47 t unladen weight, 36 to 54 t gross weight
This page gathers the Fabbripark trailers the register could not assign to a named range. The programme spans the Booster and Boostermaxxx types, the D 60, and multi-axle versions such as the TA18-27L-9LS, whose designation refers to the axle count of the combination; these are throughout heavy special trailers for large and heavy loads. The span from around 13 to over 47 tonnes unladen weight shows how much the individual versions differ in frame design and axle count.
Read on 3 more paragraphs
The register lists here 5 versions with unladen weights from 13,000 to 47,200 kg, gross weights from 36,000 to 54,000 kg, lengths from 13,630 to 14,670 mm and widths around 2,550 mm.
Trailers of this weight class carry construction machinery, plant components and other oversized goods that regular semi-trailers can no longer take; such combinations generally require an abnormal-load permit for road use and are usually run with an escort vehicle. Operators turn to them when neither a standard semi-trailer nor a low-loader reaches the required axle-load distribution or payload.
On used heavy-load trailers, the condition of the frame welds for fatigue cracks matters, the function of hydraulically steered axles, tyres and brakes across the high axle count, ramps and loading equipment, and the history of abnormal-load permits and inspections. Given the high axle loads, the wheel hubs and bearing play are also worth checking; spare parts run through heavy-haulage specialists.
Technical data
Dimensions and weights
| Length | 14,670 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 10,630 mmcorrect |
| Unladen weight | 13,000 kgcorrect |
| Gross vehicle weight | 45,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Fabbripark D 60 weigh?
The unladen weight is 13,000 kg.
What is the gross vehicle weight of the Fabbripark D 60?
45,000 kg.
Up to what speed is the Fabbripark D 60 approved?
Approved up to 100 km/h.
What are the dimensions of the Fabbripark D 60?
14,670 mm × 2,550 mm.
When was the Fabbripark D 60 built?
Production years: 2012.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
