EMS 250M-8

Series: Other models

Source: https://www.kleinanzeigen.de/s-anzeige/12v-kompressor-ems-25

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The EMS 250M-8 is a three-phase induction motor built by EMS. The rated output is 30 kW. The motor is eight-pole, which at 50 Hz gives a synchronous speed of 750 rpm. The rated voltage is 415 V. The housing is frame size 250. The protection class is IP55. The efficiency is 91.5 per cent at full load, 91.7 per cent at 75 per cent load and 90.8 per cent at half load. Mounting arrangements to IEC 60034-7: B3, B5, B35 and B14. The motor is built in China. The data is based on the Australian MEPS registration under standard AS/NZS 1359.5:2000 (Legacy); measured to IEC 60034-2-1 (Edition 2.0). Rated output across the EMS range ranges from 0.75 to 55 kW; the 250M-8 sits in the middle of that range with 30 kW. Its immediate neighbours are the 225M-8 below it with 22 kW and the 200L2-2 above it with 37 kW. 59 EMS models are on record. The model is listed under Electric motors. 22 verified figures from 1 source are on file.

Technical data

Engine

Rated output30 kWcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles8correct
Protection classIP55correct
Frame size250correct
Mounting (IEC 60034-7)B3, B5, B35, B14correct
Efficiency at full load91.51 %correct
Efficiency at 75 % load91.68 %correct
Efficiency at half load90.77 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedAS/NZS 1359.5:2000 (Legacy)correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the EMS 250M-8 have?

The EMS 250M-8 delivers 30 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
