Dressta TD10R Crawler

The Dressta TD10R is a model in the Dressta Crawler Tractor series. The engine delivers 111.5 hp (75.3 kW), with a displacement of 4,501.5 cm³. The engine comes from Cummins. Torque is 414.9 Nm. Rated speed is 2,500 rpm. Ground clearance is 381 mm. The tank holds 170.3 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,500 rpm. The cooling system holds 18.5 litres. The oil fill is 11.4 litres. The electrical system runs on 12 V. The engine fitted is the QSB4,5. The Dressta Crawler Tractor series covers 25 models. Rated output within it ranges from 81.1 to 552.6 hp; the TD10R sits at the bottom of that range with 111.5 hp. Its immediate neighbours are the TD9M LGP below it with 100.4 hp and the TD14M above it with 175.4 hp. 32 Dressta models across 3 series are on record. The model is listed under Mining equipment. 16 verified figures from 1 source are on file.
