Discovery Energy KDW1003(3600a)

Built: 2014-2019 · Series: Other models

More machines from model year 2014

Source: https://www.lectura-specs.com/en/model/components/engines-ko

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Discovery Energy KDW1003(3600a) is a machine built by Discovery Energy. Production: 2014-2019. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 18 kW. The engine is naturally aspirated. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through indirect injection. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Discovery Energy range ranges from 4 to 105 kW; the KDW1003(3600a) sits at the bottom of that range with 18 kW. Its immediate neighbours are the KDW 1003 (2850 RPM) below it with 17 kW and the KDW1404B6(2500RPM) above it with 19 kW. 340 Discovery Energy models are on record. The model is listed under Non-road diesel engines. 23 verified figures from 1 source are on file.

Discovery Energy – other nonroad diesel engines: the collective page of small diesel generator-set engines outside the named ranges, 4 to 50 kW from one- to four-cylinders, Tier 2 to Tier 4 Final

Discovery Energy appears in the US EPA certification data as a distribution and certification brand for small-displacement diesel engines, chiefly for generator sets; the model designations on this page such as 11LD625, 9LD625 or KD 350 echo the naming of the classic Italian LD and KD engine ranges in their nomenclature, though the exact manufacturer attribution cannot be reliably established from the data at hand. This page gathers the engines the register could not assign to a named range, with speed variants such as "2400 RPM", "2600 RPM" and "3000 RPM" in the model name, pointing to different mains-frequency or application versions of the same base engine.

Read on 3 more paragraphs

The register lists here 197 versions with 4 to 50 kW rated output at 1,500 to 4,300 rpm, from one- to four-cylinders with 75 to 95 mm bore and 66 to 102 mm stroke, torques from 10 to 300 Nm. Indirect injection prevails with around 146 against 51 direct-injection versions; among the emission stages Tier 4 (Final or Phase-in) leads with 114 ahead of Interim Tier 4 with 80 and a handful of Tier 2 engines.

Engines of this class and power range chiefly drive portable and stationary diesel generator sets, plus pumps and small construction compressors; the wide speed band up to 4,300 rpm is typical of air-cooled small diesels in generator applications.

On a used purchase, on these predominantly air- or oil-cooled small engines oil level and oil consumption count, the glow-plug system and cold-start behaviour, anti-vibration mounts and the condition of the exhaust system, and on generator sets the condition of the flanged alternator; given the rather niche nature of this brand, parts supply is worth clarifying in advance, as no wide dealer network is known.

Sources: Kennwerte der Modelle Discovery Energy (weitere Nonroad-Dieselmotoren)

Technical data

Engine

Engine familyHKHXL1.37SF1correct
Engine familiesHKHXL1.37SF1; KKHXL1.37SF1; FKHXL1.37SF1; EKHXL1.37SF1; JKHXL1.37SF1; GKHXL1.37SF1correct
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output18 kWcorrect
Power band8<=kW<19correct
Rated speed3,600 rpmcorrect
Maximum torque50 N·mcorrect
Speed at max. torque2,200 rpmcorrect
Cylinders3correct
Cylinder layoutin linecorrect
Bore75 mmcorrect
Stroke77.6 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectionindirect injectioncorrect
Aspirationnaturally aspiratedcorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

Built from2014correct
Built to2019correct
Model year from2014correct
Model year to2019correct
Sales regionbothcorrect

Frequently asked questions

How much power does the Discovery Energy KDW1003(3600a) have?

The Discovery Energy KDW1003(3600a) delivers 18 kW.

When was the Discovery Energy KDW1003(3600a) built?

Production years: 2014-2019.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
