Davey 862
Series: Other models
The Davey 862 is a three-phase induction motor built by Davey. The rated output is 2.2 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 415 V. The protection class is IP56. The efficiency is 86.1 per cent at full load, 85.8 per cent at 75 per cent load and 83.5 per cent at half load. The mounting arrangement to IEC 60034-7 is B3. The motor is built in Australia. The values are recorded in the Australian MEPS registration under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Davey range ranges from 1.3 to 3.2 kW; the 862 sits in the middle of that range with 2.2 kW. Its immediate neighbours are the 869 below it with 1.9 kW and the 864 above it with 2.43 kW. 9 Davey models are on record. The model is listed under Electric motors. 21 verified figures from 1 source are on file.
Technical data
Engine
| Rated output | 2.2 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP56correct |
| Frame size | Davey Designcorrect |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 86.1 %correct |
| Efficiency at 75 % load | 85.75 %correct |
| Efficiency at half load | 83.48 %correct |
Origin and approval
| Country of manufacture | Australiacorrect |
|---|---|
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
