DAF FAS CF
Built: 2012-2013 · Series: FAS
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
DAF FAS – chassis with a liftable trailing axle: from the classic 2000 and 3300-series types to CF and XF105, six-cylinders, 268 to 355 kW, up to 28,000 kg gross weight
In DAF's chassis logic, the S marks a liftable trailing axle that, together with the basic 4x2 FA chassis, makes a 6x2 three-axle truck: unlike the fixed axle of the FAN chassis, it can be raised when empty or partly loaded to save tyres and tolls. The collective page spans the classic DAF 2000 and 2800-series types of the 1980s, the 3300 and 3600 series and the current CF75, CF85 and XF105 chassis.
Read on 3 more paragraphs
The register lists here 44 versions with 268 to 355 kW from six-cylinders throughout of 9,186 to 12,902 cm³ displacement, unladen weights from 8,690 to 18,000 kg, gross weights from 20,000 to 28,000 kg, lengths from 6,600 to 11,650 mm and widths from 2,460 to 2,600 mm.
The liftable trailing axle suits duties with changing loads, such as groupage haulage, tankers or concrete mixers, where vehicles often return partly loaded or empty; on DAF 6x2 chassis it is the more common variant compared with the rigid FAN axle. Raising the third axle also cuts tyre wear and the road tolls charged according to the number of axles bearing on the road.
On a used example, the hydraulics or pneumatics of the axle-lift mechanism, corrosion on the frame and axle guides, the condition of the engine and turbocharger and the gearbox and clutch count; on the older 2000 and 3000-series types, parts availability through specialist dealers, on CF and XF the regular DAF network.
Sources: Kennwerte der Modelle DAF FAS, DAF Trucks (Hersteller)
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 12,902 cm³correct |
Dimensions and weights
| Length | 10,800 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 6,700 mmcorrect |
| Unladen weight | 13,170 kgcorrect |
| Gross vehicle weight | 28,000 kgcorrect |
Drivetrain and chassis
| Wheels | 10correct |
|---|---|
| Top speed | 90 km/hcorrect |
Frequently asked questions
How much does the DAF FAS CF weigh?
The unladen weight is 13,170 kg.
What is the gross vehicle weight of the DAF FAS CF?
28,000 kg.
What engine does the DAF FAS CF have?
6 cylinders, 12,902 cm³ displacement.
How fast does the DAF FAS CF go?
Top speed is 90 km/h.
What are the dimensions of the DAF FAS CF?
10,800 mm × 2,550 mm.
When was the DAF FAS CF built?
Production years: 2012-2013.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
