Daewoo S75V

Series: Daewoo Midi Excavator

Source: https://www.technikboerse.at/mclp/gebrauchte-baumaschinen t

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Daewoo Midi Excavator series from Daewoo includes the S75V. The engine delivers 39 kW, has 4 cylinders, with a displacement of 3,318.4 cm³. Torque is 235.1 Nm. Rated speed is 1,900 rpm. The unladen weight is 8,000 kg. Ground clearance is 365.8 mm. The tank holds 110.2 litres. Maximum torque is reached at 1,425 rpm. The pump delivers 135.1 l/min. The hydraulic tank holds 150.3 litres. Working pressure is 274.4 bar. The cooling system holds 10.2 litres. The oil fill is 9.8 litres. The electrical system runs on 12 V. The engine fitted is the 4TNV98-XDB. Rated output across the Daewoo range ranges from 7 to 337.8 kW; the S75V sits at the bottom of that range with 39 kW. Its immediate neighbours are the S55V below it with 38.3 kW and the DSL802 above it with 47.7 kW. 34 Daewoo models across 12 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model	4TNV98-XDBcorrect
Power	39 kWcorrect
Rated speed	1,900 rpmcorrect
Torque	235.1correct
Speed at max. torque	1,425 rpmcorrect
Cylinders	4correct
Displacement	3,318.4 cm³correct
Aspiration	naturally aspiratedcorrect
Coolant capacity	10.2 lcorrect
Engine oil capacity	9.8 lcorrect

Dimensions and weights

Ground clearance	365.8correct
Unladen weight	8,000 kgcorrect

Drivetrain and chassis

System voltage	12 Vcorrect

Working data

Pump flow	135.1 l/mincorrect
Hydraulic oil capacity	150.3 lcorrect
Hydraulic pressure	274.4 barcorrect
Fuel tank capacity	110.2 lcorrect

Other data

Height	2,630.4correct

Where this model stands

Power-to-weight ratio: 4.9 kW/t (39 kW / 8 t)

Stronger than 8% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Daewoo S75V have?

The Daewoo S75V delivers 39 kW.

How much does the Daewoo S75V weigh?

The unladen weight is 8,000 kg.

What engine does the Daewoo S75V have?

4 cylinders, 3,318 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
