Daewoo S140WV

Series: Daewoo Mobile Excavator

Source: https://www.technikboerse.at/mclp/gebrauchte-baumaschinen

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The S140WV from Daewoo is part of the Daewoo Mobile Excavator series. The engine delivers 96 kW, with a displacement of 5,786.3 cm³. The wheelbase measures 2,801.1 mm. Ground clearance is 350.5 mm. The tank holds 280.1 litres. The gearbox has 2 forward gears. The pump delivers 324 l/min. The hydraulic tank holds 168.1 litres. Working pressure is 343 bar. The cooling system holds 31 litres. The oil fill is 19.3 litres. The engine fitted is the DB58TIS. Tyre size: 9,00-20-14PR(OTR). Rated output across the Daewoo range ranges from 7 to 337.8 kW; the S140WV sits in the lower part of that range with 96 kW. Its immediate neighbours are the S175LCV Narrow Track below it with 88.1 kW and the MEGA200-V above it with 102.9 kW. 34 Daewoo models across 12 series are on record. The model is listed under Excavators & compaction. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine modelDB58TIScorrect
Power96 kWcorrect
Displacement5,786.3 cm³correct
Coolant capacity31 lcorrect
Engine oil capacity19.3 lcorrect

Dimensions and weights

Wheelbase2,801.1correct
Ground clearance350.5correct

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Forward gears2correct
Tyre size9.00-20-14PR(OTR)correct

Working data

Pump flow324 l/mincorrect
Hydraulic oil capacity168.1 lcorrect
Hydraulic pressure343 barcorrect
Fuel tank capacity280.1 lcorrect

Other data

Height3,118.1correct

Frequently asked questions

How much power does the Daewoo S140WV have?

The Daewoo S140WV delivers 96 kW.

What engine does the Daewoo S140WV have?

5,786 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →

Sources: [1]
