CMG XPA180L

Series: Other models

Source: https://www.kleinanzeigen.de/s-anzeige/big-ideas-einfach-erk

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

CMG lists the XPA180L as a three-phase induction motor. The rated output is 15 kW. The motor is six-pole, which at 50 Hz gives a synchronous speed of 1,000 rpm. The rated voltage is 400 V. The housing is frame size 180 L in foot-mounted form. The protection class is IP66. The efficiency is 92.2 per cent at full load and 92.5 per cent at 75 per cent load. The motor is built in China. The figures come from the Australian MEPS register under the GEMS Determination 2012; measured to AS 1359.102.1:1997. Rated output across the CMG range ranges from 0.75 to 160 kW; the XPA180L sits at the bottom of that range with 15 kW. Its immediate neighbours are the XPA160MA-2 below it with 11 kW and the Aluminium Frame HLA160L-2 above it with 18.5 kW. 815 CMG models are on record. The model is listed under Electric motors. 22 verified figures from 1 source are on file.

Technical data

Engine

Rated output15 kWcorrect

Electrical data

Rated voltage400 Vcorrect
Number of poles6correct
Protection class66correct
Frame size180 L (foot)correct
Mounting (IEC 60034-7)IM1001, 1011, 1031, 1051, 1061, 1071, 3001, 3011, 3031, 2001, 2011, 2031correct
Efficiency at full load92.2 %correct
Efficiency at 75 % load92.5 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct
Test methodAS 1359.102.1:1997correct

Frequently asked questions

How much power does the CMG XPA180L have?

The CMG XPA180L delivers 15 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
