CMG XGA
Series: Other models
CMG lists the XGA as a three-phase induction motor. The rated output is 11 kW. The motor is six-pole, which at 50 Hz gives a synchronous speed of 1,000 rpm. The rated voltage is 415 V. The housing is frame size 160 L in foot-mounted form. The protection class is IP55. The efficiency is 90.3 per cent at full load, 90.8 per cent at 75 per cent load and 90.1 per cent at half load. The motor weighs 168 kg. At full load it delivers 105.9 Nm. The motor is built in Chile. The data is based on the Australian MEPS registration under the GEMS Determination 2012; measured to AS/NZS 1359.102.3:2000. Rated output across the CMG range ranges from 0.75 to 160 kW; the XGA sits at the bottom of that range with 11 kW. Its immediate neighbours are the XPA160M-6 below it with 7.5 kW and the Aluminium Frame HLA160L-4 above it with 15 kW. 815 CMG models are on record. The model is listed under Electric motors. 28 verified figures from 1 source are on file.
Technical data
Engine
| Engine family | XGAcorrect |
|---|---|
| Engine families | XGAcorrect |
| Rated output | 11 kWcorrect |
Dimensions and weights
| Weight | 168 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 6correct |
| Protection class | IP55correct |
| Frame size | 160 L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B6, B7, B35, V1, V3, V5, V6correct |
| Efficiency at full load | 90.3 %correct |
| Efficiency at 75 % load | 90.8 %correct |
| Efficiency at half load | 90.1 %correct |
Origin and approval
| Country of manufacture | Chilecorrect |
|---|---|
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the CMG XGA have?
The CMG XGA delivers 11 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
