CMG SLA
Series: Other models
The photo shows the SGA132SB-2 from the same series.
Source: https://www.kleinanzeigen.de/s-anzeige/grundfos-3ph-motor-mg
The CMG SLA is a three-phase induction motor built by CMG. The rated output is 0.75 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 415 V. The housing is frame size 80B. The protection class is IP55. The efficiency is 75.7 per cent at full load, 75.9 per cent at 75 per cent load and 73.3 per cent at half load. The motor is built in China. The figures come from the Australian MEPS register under the GEMS Determination 2012; measured to AS 1359.102.1:1997. Rated output across the CMG range ranges from 0.75 to 160 kW; the SLA sits at the bottom of that range with 0.75 kW. Its immediate neighbours are the CWC3664BM2 above it with 0.93 kW. 815 CMG models are on record. The model is listed under Electric motors. 22 verified figures from 1 source are on file.
Technical data
Engine
| Rated output | 0.75 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 80Bcorrect |
| Mounting (IEC 60034-7) | B3, B6, B7, B8, V5, V6, B5, V1, V3, B35, V15, V36, B14, V18, V19, B34, V36correct |
| Efficiency at full load | 75.7 %correct |
| Efficiency at 75 % load | 75.9 %correct |
| Efficiency at half load | 73.28 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|---|
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
| Test method | AS 1359.102.1:1997correct |
Frequently asked questions
How much power does the CMG SLA have?
The CMG SLA delivers 0.8 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
