Changchai EV80M

Built: 2011-2012 · Series: Other models

The photo shows the 4L40B from the same series. Source: https://dvsparts.ru/statiy/article_post/korobki-peredach-dly

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Changchai EV80M is a machine built by Changchai. Production: 2011-2012. The fuel is 300-500 ppm Low Sulfur Diesel. The rated output is 12 kW. The engine is naturally aspirated. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through indirect injection. It is a four-stroke diesel engine. The cylinders are arranged in a V. Rated output across the Changchai range ranges from 4 to 36 kW; the EV80M sits in the lower part of that range with 12 kW. Its immediate neighbours are the EV80H below it with 11 kW and the 3M17B above it with 13 kW. 105 Changchai models are on record. The model is listed under Non-road diesel engines. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine familyBCHCL0.79AAAcorrect
Engine familiesBCHCL0.79AAA; CCHCL0.79AAAcorrect
Fuel300-500 ppm Low Sulfur Dieselcorrect
Rated output12 kWcorrect
Power band8<=kW<19correct
Rated speed3,000 rpmcorrect
Maximum torque38.2 N·mcorrect
Speed at max. torque3,000 rpmcorrect
Cylinders2correct
Cylinder layoutV layoutcorrect
Bore80 mmcorrect
Stroke79 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectionindirect injectioncorrect
Aspirationnaturally aspiratedcorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

Built from2011correct
Built to2012correct
Model year from2011correct
Model year to2012correct
Sales regionUSA excluding Californiacorrect

Frequently asked questions

How much power does the Changchai EV80M have?

The Changchai EV80M delivers 12 kW.

When was the Changchai EV80M built?

Production years: 2011-2012.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
