Caterpillar 2206F

Built: 2016-2026 · Series: Other models

Source: https://catused.cat.com/en/search.aspx

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Caterpillar 2206F is a machine built by Caterpillar. Production: 2016-2026. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 327 kW. The engine is turbocharged. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through direct injection. The charge air is cooled by air or coolant. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Caterpillar range ranges from 147 to 4,488 kW; the 2206F sits at the bottom of that range with 327 kW. Its immediate neighbours are the C9.3B below it with 310 kW and the 2506F above it with 353 kW. 1091 Caterpillar models across 47 series are on record. The model is listed under Non-road diesel engines. 27 verified figures from 1 source are on file.

Technical data

Engine

Engine code19correct
Engine familyHCPXL12.5HTFcorrect
Engine familiesHCPXL12.5HTF; KCPXL12.5HTF; JCPXL12.5HTF; PCPXL12.5HTF; LCPXL12.5HTF; TCPXL12.5HTF; GCPXL12.5HTF; NCPXL12.5HTF; MCPXL12.5HTF; RCPXL12.5HTF; SCPXL12.5HTFcorrect
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output327 kWcorrect
Power band130<=kW<=560correct
Rated speed2,100 rpmcorrect
Maximum torque2,010 N·mcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Cylinder layoutin linecorrect
Bore130 mmcorrect
Stroke157 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectiondirect injectioncorrect
Aspirationturbochargedcorrect
Turbocharger typeAsymmetriccorrect
Charge-air coolingbothcorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

Version19correct
Built from2016correct
Built to2026correct
Model year from2016correct
Model year to2026correct
Sales regionbothcorrect

Frequently asked questions

How much power does the Caterpillar 2206F have?

The Caterpillar 2206F delivers 327 kW.

When was the Caterpillar 2206F built?

Production years: 2016-2026.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 27 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
