Caterpillar M325C MH

Series: Caterpillar Material Handler

The photo shows the 330C MH from the same series. Source: https://www.truck1.eu/construction-machinery/caterpillar/cat

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Caterpillar M325C MH belongs to the Caterpillar Material Handler series. The engine delivers 191.6 hp (129 kW), has 6 cylinders, with a displacement of 7,200.5 cm³. Rated speed is 1,800 rpm. The wheelbase measures 3,002.3 mm. Ground clearance is 253 mm. Top speed is 20.1 km/h. The tank holds 500.1 litres. The hydraulic tank holds 350.2 litres. The cooling system holds 30.3 litres. The oil fill is 34.1 litres. The engine fitted is the 3126B ATAAC. Tyre size: 12-20 dual. The Caterpillar Material Handler series covers 14 models. Rated output within it ranges from 149 to 349.8 hp; the M325C MH sits in the lower part of that range with 191.6 hp. Its immediate neighbours are the M318D MH below it with 176.4 hp and the M325C LMH above it with 204.8 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Excavators & compaction. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine model3126B ATAACcorrect
Power191.6 hp (129 kW)correct
Rated speed1,800 rpmcorrect
Cylinders6correct
Displacement7,200.5 cm³correct
Aspirationturbochargedcorrect
Coolant capacity30.3 lcorrect
Engine oil capacity34.1 lcorrect

Dimensions and weights

Wheelbase3,002.3correct
Ground clearance253correct

Drivetrain and chassis

Tyre size12-20 dualcorrect
Top speed20.1 km/hcorrect

Working data

Hydraulic oil capacity350.2 lcorrect
Fuel tank capacity500.1 lcorrect

Frequently asked questions

How much power does the Caterpillar M325C MH have?

The Caterpillar M325C MH delivers 192 hp.

What engine does the Caterpillar M325C MH have?

6 cylinders, 7,200 cm³ displacement.

How fast does the Caterpillar M325C MH go?

Top speed is 20.1 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
