Caterpillar D6N WH XL Crawler
Series: D6N
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Caterpillar D6N — the lighter, finish-grading D6 class
The D6N covers five models in the database, all in the tight band of 108 to 111 kW and 15.9 to 19.3 tonnes — the D6N, D6N XL and D6N LGP variants plus the radial-steer D6N WH XL and D6N WH LGP. That puts the D6N at the lighter end of the D6 class, below the heavier D6R/D6T line.
Read on 4 more paragraphs
According to the manufacturer, the D6N is deliberately tuned as a mix of pulling power for classic dozing and the balance needed for finish grading — a trade-off the heavier D6 variants resolve in favour of raw pushing power instead. Its elevated-sprocket design, which keeps the final drives and axles above the track, isolates the sensitive drive components.
The D6N accordingly sees use where fine grading work is needed alongside pure dozing, for example in road and site construction, while the heavier D6 classes work more in straight earthmoving and mine-site prep.
For a used D6N, roller, track-pin and final-drive condition matter most; on the WH radial-steer variants, also check the steering clutches.
In short: the D6N isn't an older or newer generation of the D6R/D6T but a lighter variant of the D6 class run alongside it, focused on finish grading.
Sources: Kennwerte der Modelle Caterpillar D6N, — Cat D6N Medium Dozer Produktseite (cat.com)
Technical data
Engine
| Engine model | C6.6 ACERTcorrect |
|---|---|
| Power | 111.9 kWcorrect |
| Displacement | 7,193.9 cm³correct |
Dimensions and weights
| Ground clearance | 423.7correct |
|---|---|
| Unladen weight | 17,338.1 kgcorrect |
Working data
| Fuel tank capacity | 299 lcorrect |
|---|
Other data
| Cab height | 3,081.5correct |
|---|---|
| System voltage | 24 Vcorrect |
More machines with this engine (C6.6 ACERT, 12)
Where this model stands
Power-to-weight ratio: 6.5 kW/t (112 kW / 17.3 t)
Stronger than 43% of the mining equipment in the register — out of 944 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Caterpillar D6N WH XL have?
The Caterpillar D6N WH XL delivers 112 kW.
How much does the Caterpillar D6N WH XL weigh?
The unladen weight is 17,338 kg.
What engine does the Caterpillar D6N WH XL have?
7,194 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
