Caterpillar CB224B
Series: Caterpillar Vibratory Smooth Drum Roller
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Technical data
Engine
| Engine model | 2M40Lcorrect |
|---|---|
| Power | 33.4 hp (24.5 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 1,717.4 cm³correct |
| Engine oil capacity | 4.5 lcorrect |
Dimensions and weights
| Length | 2,400 mmcorrect |
|---|---|
| Width | 1,301.5correct |
| Ground clearance | 250.2correct |
| Unladen weight | 2,450 kgcorrect |
Drivetrain and chassis
| Top speed | 10.6 km/hcorrect |
|---|---|
| System voltage | 12 Vcorrect |
Working data
| Hydraulic oil capacity | 40.1 lcorrect |
|---|---|
| Fuel tank capacity | 53.8 lcorrect |
Other data
| Cab height | 2,587.8correct |
|---|
Where this model stands
Power-to-weight ratio: 10 kW/t (24 kW / 2.5 t)
Stronger than 12% of the road construction in the register — out of 667 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Caterpillar CB224B have?
The Caterpillar CB224B delivers 33.4 hp.
How much does the Caterpillar CB224B weigh?
The unladen weight is 2,450 kg.
What engine does the Caterpillar CB224B have?
2 cylinders, 1,717 cm³ displacement.
How fast does the Caterpillar CB224B go?
Top speed is 10.6 km/h.
What are the dimensions of the Caterpillar CB224B?
2,400 mm × 1,302 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 16 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
