Caterpillar 554
Series: Caterpillar Forwarder
With the 554, Caterpillar offers a model from the Caterpillar Forwarder series. The engine delivers 123.7 hp (91 kW), with a displacement of 3,982.1 cm³. Rated speed is 2,200 rpm. Ground clearance is 515.1 mm. Top speed is 24.9 km/h. The tank holds 90.1 litres. The gearbox has 2 forward gears. There are also 2 reverse gears. Maximum torque is reached at 1,600 rpm. The engine fitted is the 3054 DITA. Rated output across the Caterpillar range ranges from 18.7 to 3,599.2 hp; the 554 sits at the bottom of that range with 123.7 hp. Its immediate neighbours are the M315 below it with 123.6 hp and the 120B above it with 126.7 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Forestry equipment. 12 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | 3054 DITAcorrect |
|---|---|
| Power | 123.7 hp (91 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Displacement | 3,982.1 cm³correct |
Dimensions and weights
| Ground clearance | 515.1correct |
|---|
Drivetrain and chassis
| Gearbox type | hydrostatic transmission/mechanical gearboxcorrect |
|---|---|
| Forward gears | 2correct |
| Reverse gears | 2correct |
| Top speed | 24.9 km/hcorrect |
Working data
| Fuel tank capacity | 90.1 lcorrect |
|---|
Frequently asked questions
How much power does the Caterpillar 554 have?
The Caterpillar 554 delivers 124 hp.
What engine does the Caterpillar 554 have?
3,982 cm³ displacement.
How fast does the Caterpillar 554 go?
Top speed is 24.9 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
