Caterpillar 541
Series: Caterpillar Feller Buncher
With the 541, Caterpillar offers a model from the Caterpillar Feller Buncher series. The engine delivers 309.2 hp (210.3 kW), with a displacement of 8,801.5 cm³. Rated speed is 2,100 rpm. Ground clearance is 74.2 mm. The tank holds 1,181 litres. The hydraulic tank holds 370.2 litres. The cooling system holds 61.3 litres. The oil fill is 39.4 litres. The electrical system runs on 24 V. The engine fitted is the C9 ACERT. The Caterpillar Feller Buncher series covers 10 models. Rated output within it ranges from 250.4 to 309.2 hp; the 541 sits at the top of that range with 309.2 hp. Its immediate neighbours are the 532 below it with 287.9 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Forestry equipment. 14 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | C9 ACERTcorrect |
|---|---|
| Power | 309.2 hp (210.3 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Displacement | 8,801.5 cm³correct |
| Coolant capacity | 61.3 lcorrect |
| Engine oil capacity | 39.4 lcorrect |
Dimensions and weights
| Length | 9,424.4correct |
|---|---|
| Width | 3,328.4correct |
| Ground clearance | 74.2correct |
Drivetrain and chassis
| System voltage | 24 Vcorrect |
|---|
Working data
| Hydraulic oil capacity | 370.2 lcorrect |
|---|---|
| Fuel tank capacity | 1,181 lcorrect |
Other data
| Cab height | 3,557correct |
|---|
More machines with this engine (C9 ACERT, 19)
Frequently asked questions
How much power does the Caterpillar 541 have?
The Caterpillar 541 delivers 309 hp.
What engine does the Caterpillar 541 have?
8,802 cm³ displacement.
What are the dimensions of the Caterpillar 541?
9,424 mm × 3,328 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
