Caterpillar 320C FM

Series: Caterpillar Log Loader

Source: https://www.technikboerse.at/gebraucht/bagger-lader-17/cater

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 320C FM from Caterpillar is part of the Caterpillar Log Loader series. The engine delivers 106.6 kW, with a displacement of 6,371.3 cm³. Ground clearance is 652.3 mm. The tank holds 400.1 litres. The pump delivers 205.2 l/min. The hydraulic tank holds 240.4 litres. Working pressure is 343 bar. The cooling system holds 30.3 litres. The oil fill is 30.3 litres. The electrical system runs on 24 V. The engine fitted is the 3066T Diesel engine. The Caterpillar Log Loader series covers 5 models. Rated output within it ranges from 106.6 to 199.8 kW; the 320C FM sits at the bottom of that range with 106.6 kW. Its immediate neighbours are the 320D FM above it with 117.1 kW. 1091 Caterpillar models across 47 series are on record. The model is listed under Excavators & compaction. 13 verified figures from 1 source are on file.

Technical data

Engine

Engine model3066T Diesel enginecorrect
Power106.6 kWcorrect
Displacement6,371.3 cm³correct
Coolant capacity30.3 lcorrect
Engine oil capacity30.3 lcorrect

Dimensions and weights

Width3,310.1correct
Ground clearance652.3correct

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow205.2 l/mincorrect
Hydraulic oil capacity240.4 lcorrect
Hydraulic pressure343correct
Fuel tank capacity400.1 lcorrect

Other data

Height4,550.7correct

Frequently asked questions

How much power does the Caterpillar 320C FM have?

The Caterpillar 320C FM delivers 107 kW.

What engine does the Caterpillar 320C FM have?

6,371 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
