Caterpillar 24M

Series: Caterpillar Motor Grader

Source: https://catused.com/cn/dealer.aspx?orgid=%7Bb09a7392-882c-41
With the 24M, Caterpillar offers a model from the Caterpillar Motor Grader series. The engine delivers 540.4 hp, has 6 cylinders, with a displacement of 18,099.5 cm³. Rated speed is 2,000 rpm. The unladen weight is 66,137.4 kg. The wheelbase measures 10,277.9 mm. Ground clearance is 883.9 mm. The tank holds 1,324.9 litres. The hydraulic tank holds 265 litres. Working pressure is 241.3 bar. The cooling system holds 90.8 litres. The engine fitted is the Cat C18 ACERT. Tyre size: 29,5-29 28PR. The Caterpillar Motor Grader series covers 37 models. Rated output within it ranges from 126.7 to 540.4 hp; the 24M sits at the top of that range with 540.4 hp. Its immediate neighbours are the 24H ES below it with 506.9 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Motor graders. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine modelCat C18 ACERTcorrect
Power540.4 hpcorrect
Rated speed2,000 rpmcorrect
Cylinders6correct
Displacement18,099.5 cm³correct
Coolant capacity90.8 lcorrect

Dimensions and weights

Length14,194.5correct
Wheelbase10,277.9correct
Ground clearance883.9correct
Unladen weight66,137.4 kgcorrect

Drivetrain and chassis

Gearbox typeautomatic gearbox, electronic power shiftcorrect
Tyre size29.5-29 28PRcorrect

Working data

Hydraulic oil capacity265 lcorrect
Hydraulic pressure241.3correct
Fuel tank capacity1,324.9 lcorrect

Where this model stands

Power-to-weight ratio: 6 kW/t (397 kW / 66.1 t)

Stronger than 100% of the motor graders in the register — out of 186 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Caterpillar 24M have?

The Caterpillar 24M delivers 540 hp.

How much does the Caterpillar 24M weigh?

The unladen weight is 66,137 kg.

What engine does the Caterpillar 24M have?

6 cylinders, 18,100 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
