Case IH Steiger Quadtrac STX500
Built: 2004-2006 · Series: STEIGER
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Case IH Steiger Quadtrac STX500 is a tractor from the STEIGER series, built in 2004-2006. The six-cylinder engine produces 370 kW.
It runs with tracked.
It runs on diesel; the engine is water-cooled. It was replaced by the Case IH Steiger Quadtrac STX530. Within the range, rated power spans from 260 to 450 kW; with 370 kW, the Steiger Quadtrac STX500 sits in the mid-field. Directly alongside are the Steiger 485 with 362 kW below and the Steiger 470 with 390 kW above.
Technical data
Engine
| Engine make | Cumminscorrect |
|---|---|
| Fuel | dieselcorrect |
| Power | 500 hp (370 kW)correct |
| Cylinders | 6correct |
| Displacement | 915 cu incorrect |
| Bore | 5.4 in (137,2 mm)correct |
| Stroke | 6.7 in (170,2 mm)correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 154 in (3911,6 mm)correct |
|---|---|
| Unladen weight | 53,264 lbs (24160,1 kg)correct |
Drivetrain and chassis
| Drive | tracked undercarriagecorrect |
|---|
Working data
| Lifting capacity | 19,500 lbs (8845,1 kg)correct |
|---|---|
| Fuel tank capacity | 300 galcorrect |
Origin and approval
| Plant | Fargo, North Dakota, USAcorrect |
|---|---|
| Predecessor | new modelcorrect |
| Successor | Case IH Steiger Quadtrac STX530correct |
Frequently asked questions
How much power does the Case IH Steiger Quadtrac STX500 have?
The Case IH Steiger Quadtrac STX500 delivers 500 hp.
What engine does the Case IH Steiger Quadtrac STX500 have?
6 cylinders, diesel.
When was the Case IH Steiger Quadtrac STX500 built?
Production years: 2004-2006.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
