Case IH JX 80
Built: 2011-2013 · Series: JX
More machines from model year 2011
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Case IH JX 80 is a tractor from the JX series, built in 2011-2013. The four-cylinder engine, displacing 3.2 litres, produces 60 kW.
It measures 4.25 m in length and 2.51 m in width. Empty, it weighs 3,600 kg.
Within the range, rated power spans from 40.5 to 70.6 kW; with 60 kW, the JX 80 sits in the mid-field. Directly alongside are the JX 85 (A) with 58.8 kW below and the JX 90 with 65 kW above.
Technical data
Engine
| Power | 80 hp (60 kW)correct |
|---|---|
| Rated speed | 2,500 rpmcorrect |
| Torque | 279 Nmcorrect |
| Cylinders | 4correct |
| Displacement | 3,202 cm³correct |
Dimensions and weights
| Length | 4,250 mmcorrect |
|---|---|
| Width | 2,510 mmcorrect |
| Height | 2,540 mmcorrect |
| Unladen weight | 3,600 kgcorrect |
| Gross vehicle weight | 5,800 kgcorrect |
Drivetrain and chassis
| Gearbox | 12 V/12 R and 20 V/12 Rcorrect |
|---|
Working data
| Fuel tank capacity | 92 lcorrect |
|---|
Other data
| Linkage category | Cat I/IIcorrect |
|---|---|
| PTO speed | 540/540E rpmcorrect |
Where this model stands
Power-to-weight ratio: 16.7 kW/t (60 kW / 3.6 t)
Power class: Universal (40–100 hp)
Stronger than 56% of the tractors in the register — out of 15,260 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Case IH JX 80 have?
The Case IH JX 80 delivers 80 hp.
How much does the Case IH JX 80 weigh?
The unladen weight is 3,600 kg.
What is the gross vehicle weight of the Case IH JX 80?
5,800 kg.
What engine does the Case IH JX 80 have?
4 cylinders, 3,202 cm³ displacement.
What are the dimensions of the Case IH JX 80?
4,250 mm × 2,510 mm × 2,540 mm.
When was the Case IH JX 80 built?
Production years: 2011-2013.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 17 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
