Case 85XT

Series: Case Skid Steer Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 85XT from Case is part of the Case Skid Steer Loader series. The engine delivers 81.1 hp (51.5 kW), has 4 cylinders, with a displacement of 3,916.5 cm³. Rated speed is 2,500 rpm. The wheelbase measures 1,143 mm. Ground clearance is 231.1 mm. Top speed is 12.2 km/h. The tank holds 65.5 litres. The pump delivers 95 l/min. The hydraulic tank holds 62.8 litres. Working pressure is 207 bar. The cooling system holds 16.7 litres. The electrical system runs on 12 V. The engine fitted is the 4-390. Tyre size: 12,00x16,5. The Case Skid Steer Loader series covers 33 models. Rated output within it ranges from 46.6 to 91.2 hp; the 85XT sits in the upper part of that range with 81.1 hp. Its immediate neighbours are the 435 below it with 79.1 hp and the 445 above it with 81.6 hp. 620 Case models across 22 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model4-390correct
Power81.1 hp (51.5 kW)correct
Rated speed2,500 rpmcorrect
Cylinders4correct
Displacement3,916.5 cm³correct
AspirationNaturalcorrect
Coolant capacity16.7 lcorrect

Dimensions and weights

Wheelbase1,143correct
Ground clearance231.1correct

Drivetrain and chassis

Tyre size12.00x16.5correct
Top speed12.2 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow95 l/mincorrect
Hydraulic oil capacity62.8 lcorrect
Hydraulic pressure207correct
Fuel tank capacity65.5 lcorrect

Other data

Height2,033correct

Frequently asked questions

How much power does the Case 85XT have?

The Case 85XT delivers 81.1 hp.

What engine does the Case 85XT have?

4 cylinders, 3,916 cm³ displacement.

How fast does the Case 85XT go?

Top speed is 12.2 km/h.
