Case 75XT

Series: Case Skid Steer Loader

Source: https://www.landwirt.com/baumaschinen/radlader/case

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Case 75XT belongs to the Case Skid Steer Loader series. The engine delivers 76 hp (51.5 kW), has 4 cylinders, with a displacement of 3,916.5 cm³. Rated speed is 2,200 rpm. The wheelbase measures 1,143 mm. Ground clearance is 226.1 mm. Top speed is 11.6 km/h. The tank holds 65.5 litres. The pump delivers 79.5 l/min. The hydraulic tank holds 62.8 litres. Working pressure is 206.8 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the 4-390. Tyre size: 12,00x16,5. The Case Skid Steer Loader series covers 33 models. Rated output within it ranges from 46.6 to 91.2 hp; the 75XT sits in the upper part of that range with 76 hp. Its immediate neighbours are the SR200 below it with 75 hp and the 435 above it with 79.1 hp. 620 Case models across 22 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model4-390correct
Power76 hp (51.5 kW)correct
Rated speed2,200 rpmcorrect
Cylinders4correct
Displacement3,916.5 cm³correct
AspirationNaturalcorrect
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase1,143correct
Ground clearance226.1correct

Drivetrain and chassis

Tyre size12.00x16.5correct
Top speed11.6 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow79.5 l/mincorrect
Hydraulic oil capacity62.8 lcorrect
Hydraulic pressure206.8correct
Fuel tank capacity65.5 lcorrect

Other data

Height2,033correct

Frequently asked questions

How much power does the Case 75XT have?

The Case 75XT delivers 76 hp.

What engine does the Case 75XT have?

4 cylinders, 3,916 cm³ displacement.

How fast does the Case 75XT go?

Top speed is 11.6 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
