Mercedes Benz 314
Built: 1996–2006 · Series: Vans up to 3.5 t (Class N1)
Sprinter and Vito — what the three-digit number says
On Mercedes vans the three-digit number is not a model name but a shorthand for two facts. The first digit gives the weight class, the following two the power class. A Sprinter 313 CDI produces 129 hp, a 316 CDI 156 hp — the number rises with engine output while the leading 3 holds the class.
Read on 3 more paragraphs
More important than the number for a used purchase, however, is the internal series code. W906 denotes the Sprinter generation from June 2006 to December 2019 — thirteen years under one code. W907 and W910 followed. Comparing two offers both called "Sprinter 313", look for the series code and the year, not the type number.
Within the W906 there was a technical break: from mid-2009 the four-cylinder diesels came with the OM 651 engine, coupled to a six-speed manual designed for commercial use. A 2008 vehicle and a 2012 one carry the same type designation and have different engines.
Entries in this class come largely from official registration data. Dimensions, weights and axle counts are reliable; equipment, body height and wheelbase of individual vehicles are not consistently recorded there and should be checked on the vehicle itself when buying.
Sources: DeWiki: Mercedes-Benz Sprinter, auto-wiki: W906, ADAC
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,295 cm³correct |
Dimensions and weights
| Length | 5,650 mmcorrect |
|---|---|
| Width | 2,020 mmcorrect |
| Wheelbase | 4,020 mmcorrect |
| Unladen weight | 2,103 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 160 km/hcorrect |
Frequently asked questions
How much does the Mercedes Benz 314 weigh?
The unladen weight is 2,103 kg.
What is the gross vehicle weight of the Mercedes Benz 314?
3,500 kg.
What engine does the Mercedes Benz 314 have?
4 cylinders, 2,295 cm³ displacement.
What are the dimensions of the Mercedes Benz 314?
5,650 mm × 2,020 mm.
When was the Mercedes Benz 314 built?
Production years: 1996–2006.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
