Mercedes Benz 114

Built: 2000–2001 · Series: Vans up to 3.5 t (Class N1)

More machines from model year 2000

114 from Mercedes Benz falls into the category Vans up to 3.5 t (Class N1). According to the available register data, the recorded vehicles date from 2000 to 2001. The van is 4,660 mm long and 1,880 mm wide. Its kerb weight comes to 2,030 kg. Fully loaded, it may not exceed 2,700 kg. The engine has 4 cylinders, with a displacement of 2,295 cm³. Axle to axle, the wheelbase is 3,000 mm. It runs on 4 wheels. The Dutch vehicle register lists 2 examples of this model. Top speed is 171 km/h.

Sprinter and Vito — what the three-digit number says, what the W906 series code means and why EU class N1 up to 3.5 tonnes needs only a category B licence

On Mercedes vans the three-digit number is not a model name but a shorthand for two facts. The first digit gives the weight class, the following two the power class. A Sprinter 313 CDI produces 129 hp, a 316 CDI 156 hp — the number rises with engine output while the leading 3 holds the class.

Read on 4 more paragraphs

More important than the number for a used purchase, however, is the internal series code. W906 denotes the Sprinter generation from June 2006 to December 2019 — thirteen years under one code. W907 and W910 followed. Comparing two offers both called "Sprinter 313", look for the series code and the year, not the type number.

Within the W906 there was a technical break: from mid-2009 the four-cylinder diesels came with the OM 651 engine, coupled to a six-speed manual designed for commercial use. A 2008 vehicle and a 2012 one carry the same type designation and have different engines.

As EU class N1 vehicles up to 3.5 tonnes, the Sprinter and Vito need only a category B licence, no tachograph, and in most countries no distance-based lorry toll, which only applies to substantially heavier vehicles. Over the W906's thirteen years of production, emissions stages tightened from Euro 4 to Euro 6: early examples manage with an oxidation catalyst and particulate filter, while later Euro 6 versions additionally need SCR technology with AdBlue injection, whose tank, dosing module and NOx sensors are wear items of their own.

Entries in this class come largely from official registration data. Dimensions, weights and axle counts are reliable; equipment, body height and wheelbase of individual vehicles are not consistently recorded there and should be checked on the vehicle itself when buying.

Sources: SpecCodex register, model data: Mercedes-Benz Transporter (Klasse N1)

Technical data

Engine

Cylinders4correct
Displacement2,295 cm³correct

Dimensions and weights

Length4,660 mmcorrect
Width1,880 mmcorrect
Wheelbase3,000 mmcorrect
Unladen weight2,030 kgcorrect
Gross vehicle weight2,700 kgcorrect

Drivetrain and chassis

Wheels4correct
Top speed171 km/hcorrect

Frequently asked questions

How much does the Mercedes Benz 114 weigh?

The unladen weight is 2,030 kg.

What is the gross vehicle weight of the Mercedes Benz 114?

2,700 kg.

What engine does the Mercedes Benz 114 have?

4 cylinders, 2,295 cm³ displacement.

What are the dimensions of the Mercedes Benz 114?

4,660 mm × 1,880 mm.

When was the Mercedes Benz 114 built?

Production years: 2000–2001.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
