Baldor M35A002P320G1

Series: Other models

Source: https://baldor.co.id/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Baldor M35A002P320G1 is a three-phase induction motor built by Baldor. The rated output is 0.75 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The housing is frame size 143TC NEMA Frame. The protection class is IP44. The efficiency is 82.8 per cent at full load, 82.5 per cent at 75 per cent load and 79.7 per cent at half load. The mounting arrangement to IEC 60034-7 is B34. The motor is built in the USA. The data is based on the Australian MEPS registration under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Baldor range ranges from 0.75 to 1,119 kW; the M35A002P320G1 sits at the bottom of that range with 0.75 kW. Its immediate neighbours are the 35J302M774G1 above it with 1.1 kW. 841 Baldor models are on record. The model is listed under Electric motors. 20 verified figures from 1 source are on file.

Technical data

Engine

Rated output0.75 kWcorrect

Electrical data

Number of poles4correct
Protection classIP44correct
Frame size143TC NEMA Framecorrect
Mounting (IEC 60034-7)B34correct
Efficiency at full load82.8 %correct
Efficiency at 75 % load82.5 %correct
Efficiency at half load79.7 %correct

Origin and approval

Country of manufactureUnited States of Americacorrect
Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Baldor M35A002P320G1 have?

The Baldor M35A002P320G1 delivers 0.8 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
