Bagela BKT 80
Built: 2013-2013 · Series: BKT
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Bagela BKT – plant and equipment trailers from Kaltenkirchen: 870 to 2,600 kg unladen weight, 3,500 to 11,000 kg gross weight, BKT 27 to BKT 80 range
This page gathers Bagela's BKT range, a maker of plant and equipment trailers based in Kaltenkirchen near Hamburg. The BKT range spans the BKT 27 in two versions, the BKT 27 HA and the BKT 60 and BKT 80 for heavier payloads.
Read on 3 more paragraphs
The register lists here 5 versions with unladen weights from 870 to 2,600 kg at a gross weight of 3,500 to 11,000 kg, lengths from 4,380 to 5,150 mm and widths from 2,500 to 2,550 mm. The range therefore spans from vehicle class O2 into class O4, which covers trailers over 10,000 kg gross weight.
Trailers of this type carry mini excavators, wheel loaders, plate compactors or other plant to the site and are used by construction firms, municipalities and hire companies; depending on the version, payload ranges from single-axle equipment to a tandem trailer for several tonnes of machine weight. The wide ramps and low loading height of such trailers make it easier to drive tracked machines on and off without extra aids.
Buying used, the points that matter on plant trailers are the condition of the ramps and their locking, the load capacity and wear of the deck, the function of the overrun brake and wheel-chock holder, and corrosion on the chassis and axles. The age and condition of the tyres and the validity of the periodic roadworthiness test should also be checked before purchase; spare parts run through the Bagela dealer network.
Sources: Kennwerte der Modelle Bagela BKT
Technical data
Dimensions and weights
| Length | 5,150 mmcorrect |
|---|---|
| Width | 2,520 mmcorrect |
| Wheelbase | 4,100 mmcorrect |
| Unladen weight | 2,600 kgcorrect |
| Gross vehicle weight | 11,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Bagela BKT 80 weigh?
The unladen weight is 2,600 kg.
What is the gross vehicle weight of the Bagela BKT 80?
11,000 kg.
Up to what speed is the Bagela BKT 80 approved?
Approved up to 100 km/h.
What are the dimensions of the Bagela BKT 80?
5,150 mm × 2,520 mm.
When was the Bagela BKT 80 built?
Production years: 2013.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
