Ardor SVM
Built: 2016-2023 · Series: Other models
More machines from model year 2016
Ardor – other models: the collective page of semi-trailers of the SVM range outside the named ranges, unladen weights from 4,490 to 5,720 kg, gross weights from 38,000 to 40,000 kg
This page gathers the Ardor semi-trailers the register could not assign to a named range. The models carry the range name SVM, some supplemented by two numeric values after slashes that mark different versions of the same range in the register. Such a narrowly defined range with a uniform code points to a smaller, specialised semi-trailer manufacturer.
Read on 3 more paragraphs
The register lists here 4 versions with unladen weights from 4,490 to 5,720 kg, gross weights from 38,000 to 40,000 kg, lengths from 8,200 to 10,740 mm and widths from 2,540 to 2,550 mm.
With gross weights of 38 to 40 tonnes, the semi-trailers fall into vehicle class O4 and are built as articulated semi-trailers for general long-haul freight transport; with an unladen weight of only 4.5 to 5.7 tonnes against up to 40 tonnes gross, they allow a high payload. This makes the Ardor semi-trailers suited above all to dense, compact cargo where weight rather than volume limits the load.
Buying used, the condition of the kingpin and landing legs, the brake system, axles and tyres, and the chassis and body for corrosion and distortion matter; given the high payload rating, the condition of the suspension and the brake and lighting connections is also worth checking. On frames optimised for light weight, cracks in the heavily loaded welds around the axle suspension deserve particular attention.
Technical data
Dimensions and weights
| Length | 10,740 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 9,100 mmcorrect |
| Unladen weight | 5,600 kgcorrect |
| Gross vehicle weight | 40,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Ardor SVM weigh?
The unladen weight is 5,600 kg.
What is the gross vehicle weight of the Ardor SVM?
40,000 kg.
Up to what speed is the Ardor SVM approved?
Approved up to 100 km/h.
What are the dimensions of the Ardor SVM?
10,740 mm × 2,550 mm.
When was the Ardor SVM built?
Production years: 2016-2023.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
