AGCO LT75
Built: 2004-2006 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The AGCO LT75 is a tractor built in 2004-2006. The four-cylinder engine produces 56 kW.
The gearbox is a Power Shuttle ; Synchro Shuttle (optional) unit.
The fuel is diesel. This model followed the AGCO LT70, before the AGCO LT75A took over. Within the range, rated power spans from 16.8 to 216 kW; with 56 kW, the LT75 sits in the mid-field. Directly alongside are the GT75A with 54 kW below and the GT75A with 61.9 kW above.
Technical data
Engine
| Engine make | Cumminscorrect |
|---|---|
| Engine model | B seriescorrect |
| Fuel | dieselcorrect |
| Power | 75 hp (56 kW)correct |
| Cylinders | 4correct |
| Displacement | 274.6 cu incorrect |
| Bore | 4.09 in (103,9 mm)correct |
| Stroke | 5.19 in (131,8 mm)correct |
| Naturally aspirated | naturally aspiratedcorrect |
Dimensions and weights
| Length | 165.5 in (4203,7 mm)correct |
|---|---|
| Width | 77 in (2WD); 69.8 in (MFWD)correct |
| Height | 106.5 in (2705,1 mm)correct |
| Wheelbase | 97 in (2463,8 mm)correct |
| Unladen weight | 8, 980 lbs (2WD); 9, 500 lbs (MFWD)correct |
Drivetrain and chassis
| Drive | rear-wheel driveWD/MFWDcorrect |
|---|---|
| Gearbox | Power Shuttle; Synchro Shuttle (optional)correct |
| Forward gears | 16correct |
| Reverse gears | 16correct |
| Clutch | Wet Multi-Disccorrect |
Working data
| Lifting capacity | 7,710 lbs (3497,2 kg)correct |
|---|---|
| Fuel tank capacity | 39 galcorrect |
| PTO speed | 540/1000correct |
| Linkage category | Cat IIcorrect |
Origin and approval
| Plant | Beauvois, Francecorrect |
|---|---|
| Predecessor | AGCO LT70correct |
| Successor | AGCO LT75Acorrect |
Frequently asked questions
How much power does the AGCO LT75 have?
The AGCO LT75 delivers 75 hp.
What engine does the AGCO LT75 have?
4 cylinders, diesel.
When was the AGCO LT75 built?
Production years: 2004-2006.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
