ABM 4D100Lc-4

Series: Other models

The photo shows the 4DF112M-2 from the same series. Source: https://www.kleinanzeigen.de/s-anzeige/lindemann-885-vollver

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

ABM lists the 4D100Lc-4 as a three-phase induction motor. The rated output is 2.2 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 415 V. The housing is frame size 90. The protection class is IP55. The efficiency is 86.5 per cent at full load, 86.5 per cent at 75 per cent load and 85.5 per cent at half load. The mounting arrangement to IEC 60034-7 is B3. The motor is built in Germany. The data is based on the Australian MEPS registration under standard AS/NZS 1359.5:2004; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the ABM range ranges from 2.2 to 7.5 kW; the 4D100Lc-4 sits at the bottom of that range with 2.2 kW. Its immediate neighbours are the 4 DF 100 Lb - 2LK above it with 3 kW. 14 ABM models are on record. The model is listed under Electric motors. 22 verified figures from 1 source are on file.

ABM – other models: the collective page of MEPS-registered three-phase motors from the German maker outside the named ranges, frame sizes 90 to 132, 2.2 to 7.5 kW, exclusively two-pole

This page gathers the ABM three-phase motors the Australian energy-efficiency register could not assign to a named range. All 14 motors listed here come from German manufacture. Model designations such as 4 DF 100 Lb - 2LK or 4DF112M-2 combine the IEC frame size (100, 112) with the -2 pole-count suffix for the exclusively two-pole versions; the DF and LK codes mark different build forms within the range.

Read on 3 more paragraphs

The register lists here 14 versions with 2.2 to 7.5 kW, exclusively two-pole, full-load and 75%-load efficiencies both from 86.5 to 90.5%. Frame sizes run from 90 to 132, protection is IP54 and IP55, supply voltage runs from 200/400 V through 400 V to the multi-voltage 400/690 V. Testing followed AS/NZS 1359.5:2004 and the 2012 and 2019 GEMS determinations, mostly with test method B; none of the 14 motors reaches a documented High Efficiency classification.

With this small, exclusively two-pole range, ABM supplements larger international suppliers such as ABB, Siemens or WEG in the German market and in export certified for the Australian market, with applications in pumps, fans and compressors that need high speed in a compact frame.

When buying used, bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, voltage and protection rating all matter; spares run through the German specialist electric-motor trade.

Sources: Kennwerte der Modelle ABM (weitere Modelle, MEPS-Registrierungen)

Technical data

Engine

Rated output2.2 kWcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles2correct
Protection classIP55correct
Frame size90correct
Mounting (IEC 60034-7)B3correct
Efficiency at full load86.5 %correct
Efficiency at 75 % load86.5 %correct
Efficiency at half load85.5 %correct

Origin and approval

Country of manufactureGermanycorrect

Other data

Standard appliedAS/NZS 1359.5:2004correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the ABM 4D100Lc-4 have?

The ABM 4D100Lc-4 delivers 2.2 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
