ABB M3JP315MLA2

The ABB M3JP315MLA2 is a three-phase induction motor built by ABB. The rated output is 184.99 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 400 V. The housing is frame size 315. The protection class is IP55, IP56 and IP65. The efficiency is 95.9 per cent at full load, 95.8 per cent at 75 per cent load and 95.1 per cent at half load. The motor weighs 1,190 kg. At full load it delivers 592 Nm. Mounting arrangements to IEC 60034-7: B3, B5, B8, B35, V1, V3, V5 and V6. Stated countries of manufacture: Finland, China and Poland. The figures come from the Australian MEPS register under the GEMS Determination 2012; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the ABB range ranges from 0.75 to 185 kW; the M3JP315MLA2 sits at the top of that range with 184.99 kW. Its immediate neighbours are the M3KP315MLA4 below it with 184.9 kW and the M3GP315SMB8 above it with 185 kW. 2143 ABB models across 2 series are on record. The model is listed under Electric motors. 27 verified figures from 1 source are on file.
