ABB M3GP200MLC4

The ABB M3GP200MLC4 is a three-phase induction motor built by ABB. The rated output is 37 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The housing is frame size 200 M in foot-mounted form. The protection class is IP21, IP55, IP56 and IP65. The efficiency is 92.8 per cent at full load, 92.9 per cent at 75 per cent load and 92.1 per cent at half load. The motor weighs 320 kg. Mounting arrangements to IEC 60034-7: B3, B5, B8, B35, V1, V3, V5 and V8. Stated countries of manufacture: Finland and Poland. The values are recorded in the Australian MEPS registration under the GEMS Determination 2012; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the ABB range ranges from 0.75 to 185 kW; the M3GP200MLC4 sits in the lower part of that range with 37 kW. Its immediate neighbours are the M3KP250SMA8 below it with 30 kW and the M2BA 225SMA 2G above it with 45 kW. 2143 ABB models across 2 series are on record. The model is listed under Electric motors. 25 verified figures from 1 source are on file.
