ABB M3APP200MLB6

The ABB M3APP200MLB6 is a three-phase induction motor built by ABB. The rated output is 18.5 kW. The motor is six-pole, which at 50 Hz gives a synchronous speed of 1,000 rpm. The rated voltage is 400 V. The housing is frame size 200 M in foot-mounted form. The protection class is IP55. The efficiency is 92.4 per cent at full load, 92.5 per cent at 75 per cent load and 91.3 per cent at half load. The motor weighs 185 kg. At full load it delivers 179 Nm. Mounting arrangements to IEC 60034-7: B3, B5 and B35. The motor is built in Sweden. The data is based on the Australian MEPS registration under standard AS/NZS 1359.5:2004; measured to AS/NZS 1359.102.3:2000. Rated output across the ABB range ranges from 0.75 to 185 kW; the M3APP200MLB6 sits at the bottom of that range with 18.5 kW. Its immediate neighbours are the M3KP200MLA8 below it with 15 kW and the M2BA 180MLA 2G above it with 22 kW. 2143 ABB models across 2 series are on record. The model is listed under Electric motors. 25 verified figures from 1 source are on file.
