ABB M3
Series: Other models
ABB lists the M3 as a three-phase induction motor. The rated output is 0.75 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 415 V. The housing is frame size 90. The protection class is IP55, IP56 and IP65. The efficiency is 80.9 per cent at full load, 78.2 per cent at 75 per cent load and 72.6 per cent at half load. The motor weighs 40 kg. Mounting arrangements to IEC 60034-7: B3, B5, B8, B35, V1, V3, V5 and V6. The motor is built in Finland. The figures come from the Australian MEPS register under the GEMS Determination 2012; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the ABB range ranges from 0.75 to 185 kW; the M3 sits at the bottom of that range with 0.75 kW. Its immediate neighbours are the M2AA90 above it with 1.1 kW. 2143 ABB models across 2 series are on record. The model is listed under Electric motors. 28 verified figures from 1 source are on file.
Technical data
Engine
| Engine family | M3correct |
|---|---|
| Engine families | M3correct |
| Rated output | 0.75 kWcorrect |
Dimensions and weights
| Weight | 40 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55, IP56, IP65correct |
| Frame size | 90correct |
| Mounting (IEC 60034-7) | B3, B5, B8, B35, V1, V3, V5, V6correct |
| Efficiency at full load | 80.9 %correct |
| Efficiency at 75 % load | 78.2 %correct |
| Efficiency at half load | 72.6 %correct |
Origin and approval
| Country of manufacture | Finlandcorrect |
|---|---|
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the ABB M3 have?
The ABB M3 delivers 0.8 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
