ABB M2QA250

The ABB M2QA250 is a three-phase induction motor built by ABB. The rated output is 30 kW. The motor is eight-pole, which at 50 Hz gives a synchronous speed of 750 rpm. The rated voltage is 400 V. The housing is frame size 250 M in foot-mounted form. The protection class is IP55. The efficiency is 91.3 per cent at full load, 90.1 per cent at 75 per cent load and 90 per cent at half load. The motor weighs 392 kg. At full load it delivers 387 Nm. Mounting arrangements to IEC 60034-7: B3, B5 and B35. The motor is built in China. The values are recorded in the Australian MEPS registration under standard AS/NZS 1359.5:2000 (Legacy); measured to IEC 60034-2-1 (Edition 2.0). Rated output across the ABB range ranges from 0.75 to 185 kW; the M2QA250 sits in the lower part of that range with 30 kW. Its immediate neighbours are the M3BP160MLE2 below it with 27 kW and the M2BA 200MLB 2G above it with 37 kW. 2143 ABB models across 2 series are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.
